35X 6~210mm 2MP Drone Zoom Camera Module
VS-UAZ2035N· 1/1.8” high sensitivity CMOS, 2.13MP.
· 35× optical zoom, 6~210mm.
· Supports Optical-Defog, HLC, BLC, WDR.
· High-precision & stability-enhanced design.
· Convenient Ground Control Station operation.
· Modular design, strong scalability, open SDK.
· Intelligent target tracking.
>35X optical zoom, 6~210mm, 4X digital zoom
>Using SONY starlight level low illumination sensor, good imaging effect
>Max. Resolution: 1920*1080@25/30fps (50/60fps Optical-Defog version).
>Rich interface, support network port
>Support H265 and H264
>Intelligent tracking function based on optical flow
>Fast and accurate focusing
>Supporting flight log such as longitude, latitude, height
|
This footage was shot by 35X 2MP Starlight Drone Camera. Drone zoom block camera specially designed for industrial UAV. The control is simple and compatible with VISCA protocol. If you are familiar with the control of Sony block camera, it is easy to integrate our camera. |
|
35x optical zoom and 4x digital zoom provides the power to see objects which is long distance away. Supports recording GPS information when take picture. This can be used for the flight platform to view the trajectory after event |
 |
 |
56G micro SD card supported. Recording files can be stored as MP4. The video file will be lost when the camera is powered off abnormally, we can repair the file when the camera is not fully stored. |
| Support H265/HEVC encoding format which can greatly save transmission bandwidth and storage space. |
 |
 |
Built in intelligent tracking. The camera will feed back the position of the target being tracked by RS232. |
| Camera | ||||
| Sensor | Type | 1 / 2" Sony Progressive Scan CMOS | ||
| Effective Pixels | 2.13 M Pixels | |||
| Lens | Focal Length | 6 ～ 210mm | ||
| Optical Zoom | 35× | |||
| Aperture | FNo: 1.5 ～ 4.8 | |||
| HFOV (°) | 61.9° ～ 1.9° | |||
| VFOV (°) | 37.2° ～ 1.1° | |||
| DFOV (°) | 69.0° ～ 2.2° | |||
| Close Focus Distance | 1m ～ 1.5m (Wide ～ Tele) | |||
| Zoom Speed | 4.5 Sec (Optics, Wide ～ Tele) | |||
| DORI（M）(It is calculated based on the camera sensor specification and the criteria given by EN 62676-4:2015) | Detect | Observe | Recognize | Identify |
| 2315 | 918 | 463 | 231 | |
| Video & Audio Network | Compression | H.265/H.264/H.264H/MJPEG | ||
| Resolution | Main Stream: 1080P@25/30fps; 1280*960@25/30fps; 720P@25/30fps
Sub Stream1: D1@25/30fps; CIF@25/30fps Sub Stream2: 1080P@25/30fps; 720P@25/30fps; D1@25/30fps |
|||
| Video Bit Rate | 32kbps ～ 16Mbps | |||
| Audio Compression | AAC / MP2L2 | |||
| Storage Capabilities | TF card, up to 256GB | |||
| Network Protocols | ONVIF, HTTP, RTSP, RTP, TCP, UDP | |||
| Upgrade | Support | |||
| Min Illumination | Colour: 0.001Lux/F1.5; B/W: 0.0001Lux/F1.5 | |||
| Shutter Speed | 1 / 3 ～ 1 / 30000 Sec | |||
| Noise Reduction | 2D / 3D | |||
| Image Settings | Saturation, Brightness, Contrast, Sharpness, Gamma, etc. | |||
| Flip | Support | |||
| Exposure Model | Auto/Manual/Aperture Priority/Shutter Priority/Gain Priority | |||
| Exposure Comp | Support | |||
| WDR | Support | |||
| BLC | Support | |||
| HLC | Support | |||
| S/N Ratio | ≥ 55dB（AGC Off, Weight ON） | |||
| AGC | Support | |||
| White Balance (WB) | Auto/Manual/Indoor/Outdoor/ATW/Sodium Lamp/Natural/Street Lamp/One Push | |||
| Day/Night | Auto (ICR)/Manual (Colour, B/W) | |||
| Digital Zoom | 16× | |||
| Focus Model | Auto/Manual/Semi-Auto | |||
| Defog | Electronic-Defog (Default); Optical-Defog (Option) | |||
| Image Stabilisation | Electronical Image Stabilisation (EIS) | |||
| External Control | 1× TTL3.3V, Compatible with VISCA protocols | |||
| Video Output | Network | |||
| Baud Rate | 9600 (Default) | |||
| Operating Conditions | -30℃ ～ +60℃; 20﹪ to 80﹪RH | |||
| Storage Conditions | -40℃ ～ +70℃; 20﹪ to 95﹪RH | |||
| Weight | 244g | |||
| Power Supply | +9 ～ +12V DC (Recommend: 12V) | |||
| Power Consumption | Static: 4.0W; Max: 5.5W | |||
| Dimensions (mm) | Length * Width * Height：122.4*54*62.2 | |||
