Long Range Bi-Spectrum Night Vision PTZ Camera

Short Description:

> 4Mp high-resolution visible light camera, with a maximum configuration of 1000mm camera.

> 1280*1024 thermal camera with a maximum focal lens of 37.5-300mm

> Servo motor drive, with a horizontal rotation speed of up to 180°/s and a positioning accuracy of up to 0.003°

> Corrosion-resistant ASTM B117 / ISO 9227 (2000 hours) compliant with ship classification standards

> Support radar-guided gimbal tracking, with a gimbal rotation speed level of 65535 and a speed resolution better than 0.001°/s

> Support motor stall detection, automatically stopping rotation when the motor rotates abnormally, effectively preventing damage to the turbine and motor

> Support customization, 640 * 512 thermal optional, various lenses available, laser ranging optional

Module Name: VS-PTZ4052-RVA3008-P60B/VS-PTZ4088-RVA3008-P60B

CONTACT NOW

Overview

Product Detail

Product Tags

Feedback (2)

Bi spectrum PTZ positioning systems is specially designed for long distance security of border and coastal defense.
The PTZ structure is designed with double side loading, which is beautiful, strong wind resistance and high precision and high reliability. It can be used with a variety of visible zoom camera and thermal imaging.

Previous: NDAA 256×192 Thermal Network Hybrid Speed Dome Camera

Next: Long Range Night Vision Bi-spectrum Network PTZ Camera

Visible
Image Sensor	1 / 1.8" Progressive Scan CMOS
Focal length	15~775mm	11.3~1000mm
Optical Zoom	52X	88X
Aperture	FNo：2.8 ～ 8.2	FNo：2.1 ～ 7.5
Image stabilization	OIS	EIS
Min. Illumination	Color：0.05Lux/F2.8 ,AGC ON	Color：0.05Lux/F2.0 ,AGC ON
S/N Ratio	≥ 55dB（AGC Off,Weight ON）
AGC	Support
Defog	Optical
Thermal
Detector Type	Vanadium oxide uncooled focal plane detector
Pixel Pitch	12μm
Spectral Range	8μm ～ 14μm
Sensitivity (NETD)	≤50mK@f/1.0
Color Palettes	Support white heat, black heat, fusion, rainbow, etc. 20 kinds of pseudo-color adjustable
Effective Pixels	1280（H）x 1024（V）
Focal Length	25~225mm		37.5~300
Field of View	34.1° x27.6° ~3.9° X3.1°		23.1° x18.6° ~2.9° x2.3°
Aperture	F1.0~F1.5		F1.2
Focus Mode	Automatic/manual/One Push
Video and Audio
Main stream	Visible：50Hz：25fps（26881520、19201080、1280*720） Thermal：50Hz：25fps（1280×1024）
Video Compression	H.265、H.264、H.264H、H.264B、MJEPG
Audio Compression	AAC、MP2L2
Pan-tilt Unit
Movement Range	Pan: 360° (Continuous Rotate) ; Tilt: -90° ~ 90°
Speed	Pan: 0.01°～180°/Sec; Tilt: 0.01°～100°/Sec
Presets	256
3D Positioning	Support
Target Tracking	Support
Positioning Accuracy	±0.003°
Heater	Support
Wiper	Support
Fans	Support
Intelligent
Perimeter Protection	Support tripwire /support intrusion and other behavioral detection
Intelligent Tracking	Supports multiple tracking modes such as event tracking
Fire Detection	Support
Strong Light Protection	Support
Network
Network Protocols	IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP,RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
Interface
Alarm Input	7-ch
Alarm Output	2-ch
Audio Input	1-ch
Audio Output	1-ch
Communication interface	1 RJ45 10M/100M adaptive interface 1 RJ485
General
Power Supply	Standby power consumption: 30W, maximum power consumption: 180W Power supply: DC48V power adapter
Working temperature and humidity	Temperature： -40 ~ 60 ℃/22℉ ~ 140℉；humidity：<90%
Protection level	IP66
Corrosion resistance	Corrosion resistance ASTM B117/ISO 9227 (2000 hours) in accordance with classification society standards
